Titanium Forge Fittings
- Home
- Titanium Forge Fittings
Chemical Composition of SS Buttweld Fittings
| Grade |
Ti |
H |
C |
Fe |
N |
Al |
O |
V |
| Ti Grade2 |
99.2 min |
0.015 max |
0.1 max |
0.3 max |
0.03 max |
– |
0.25 max |
– |
| Ti Grade5 |
90 min |
– |
– |
0.25 max |
– |
6 min |
0.2 max |
4 min |
| Grade |
Ti |
H |
C |
Fe |
N |
Al |
O |
V |
| Ti Grade5 |
90 min |
– |
– |
0.25 max |
– |
6 min |
0.2 max |
4 min |
Mechanical Properties of SS Butt weld Pipe Fittings
| Element |
Melting Point |
Density |
Yield Strength (0.2%Offset) |
Tensile Strength |
Elongation |
| Titanium Gr. 2 |
1665 °C (3030 °F) |
4.5 g/cm3 |
Psi – 39900 , MPa – 275 |
Psi – 49900 , MPa – 344 |
20 % |
| Titanium Gr. 5 |
1632 °C (2970 °F) |
4.43 g/cm3 |
Psi – 128000 , MPa – 880 |
Psi – 138000 , MPa – 950 |
14 % |
| Element |
Melting Point |
Density |
Yield Strength (0.2%Offset) |
Tensile Strength |
Elongation |
| Titanium Gr. 5 |
1632 °C (2970 °F) |
4.43 g/cm3 |
Psi – 128000 , MPa – 880 |
Psi – 138000 , MPa – 950 |
14 % |
