Chemical Composition of SS Buttweld Fittings
| Grade |
C |
Mn |
Si |
S |
Cu |
Fe |
Ni |
| Nickel 200 |
0.15 max |
0.35 max |
0.35 max |
0.01 max |
0.25 max |
0.40 max |
99.0 min |
| Grade |
C |
Mn |
Si |
S |
Cu |
Fe |
Ni |
| Nickel 201 |
0.02 max |
0.35 max |
0.35 max |
0.01 max |
0.25 max |
0.40 max |
99.0 min |
Mechanical Properties of SS Butt weld Pipe Fittings
| Element |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| Nickel 200 |
8.9 g/cm3 |
1446 °C (2635 °F) |
Psi – 67000 , MPa – 462 |
Psi – 21500 , MPa – 148 |
45 % |
| Element |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
| Nickel 201 |
8.9 g/cm3 |
1446 °C (2635 °F) |
Psi – 67000 , MPa – 462 |
Psi – 21500 , MPa – 148 |
45 % |
